Tighten – Copernicus IR400 User Manual
Page 26
Epson_CART - Version 2012_A - May 8 2012 - Copernicus Educational Products Inc.
You will need:
(not to scale)
15A
Actual Size:
M8 lock nut
8x
R
M6 x 19mm
bolt 8x
I
Install Protective Handles
Protective handle x 2
If you plan to install the optional Side Laptop Arm,
skip this step and proceed to step 15B for instructions.
1
3
Handle insert x 4
2
M8 lock washer
8x
V
M6 barrel nut
8x
W
R
R
W
V
I
TIGHTEN!
26
