Copernicus IR400 - Manual (Page 13)

Epson_CART - Version 2012_A - May 8 2012 - Copernicus Educational Products Inc.
Slide frame x 1
You will need:
(not to scale)
4
Install Slide Frame & Slide Handle
Slide handle x 1
1
2
Insert slide handle in end of slide frame.
Insert assembly over the legs.
Ensure both sides have a
black plastic bushing in the
top.
!
2-Person Task
Ensure slide handle is on the
left side of the unit.
Please Note:
Sliding parts are lubricated with a Petroleum
based jelly to ensure smooth movement when
adjusting the height.
13
