Install back supports & secure short stretchers – Copernicus IR400 User Manual
Page 18
Epson_CART - Version 2012_A - May 8 2012 - Copernicus Educational Products Inc.
You will need:
(not to scale)
8
Install Back Supports & Secure Short Stretchers
Back supports x 2
M6 x 50mm bolt
4x
B
M6 lock
washer 4x
N
B
K
N
V
Hole indents should
always be to the outside
of the unit.
Y
Partially
threaded M8 x 50mm bolt 2x
K
K
M8 lock
washer 2x
V
M8 extra large
flat washer
2x
Y
B
N
B
N
18
