Leave very loose – Copernicus IR400 User Manual
Page 20
Epson_CART - Version 2012_A - May 8 2012 - Copernicus Educational Products Inc.
You will need:
(not to scale)
10
Board mounting frame - support x 2
M8 lock
nut 4x
R
Install Board Mounting Frame - Top & Projector Arm Support
1
Board mounting frame - top x 1
Actual Size:
R
R
LEAVE VERY LOOSE
Ensure tabs are all on one side.
