Conventions used in this Guide
This document uses the conventions shown in the following table.
Item Format Examples
Command-line entries Courier bold font face $ Open top_level_name.log
File Names Courier font face filename.ext
GUI buttons, menus and
radio buttons
Helvetica bold font face
Click OK to continue.
File → Open
Variables Italic emphasis design_dir/output.log
Window and dialog box
headings and sub-headings
Heading in quotation
marks
Under “Output Files,” select ...
Window and dialog box
names
Initial caps From the Add Files dialog box, ...
Terminologies used in this Guide
This document uses the terminologies and synonyms shown in the following table.
Terminology Synonyms Examples
Speedster22i HD1000
Refers to the Achronix FPGA
family
sBus Serial bus, SBUS
Refers to the serial bus on the
HD1000
