Achronix Speedster22i Interlaken User Manual
Page 41
0x0980
to
0x09AE
statistics
counters
RX Word Boundary Synchronization Error Statistics Registers – RO
0x0980 Bit 15:0 – returns the value contained in bits 15-0 (LSB) of RX
Word Boundary Synchronization Error Statistics register for lane 0
0x0982 Bit 15:0 – returns the value contained in bits 31-16 (MSB) of
RX Word Boundary Synchronization Error Statistics register for lane
0
0x0984 Bit 15:0 – returns the value contained in bits 15-0 (LSB) of RX
Word Boundary Synchronization Error Statistics register for lane 1
0x0986 Bit 15:0 – returns the value contained in bits 31-16 (MSB) of
RX Word Boundary Error Synchronization Statistics register for lane
1
Continues for all 12 lanes (0-11) up to address 0x09AE
0x0A00
to
0x0A2E
statistics
counters
RX Framing Error Statistics Registers – RO
0x0A00 Bit 15:0 – returns the value contained in bits 15-0 (LSB) of RX
Framing Error Statistics register for lane 0
0x0A02 Bit 15:0 – returns the value contained in bits 31-16 (MSB) of
RX Framing Error Statistics register for lane 0
0x0A04 Bit 15:0 – returns the value contained in bits 15-0 (LSB) of RX
Framing Error Statistics register for lane 1
0x0A06 Bit 15:0 – returns the value contained in bits 31-16 (MSB) of
RX Framing Error Statistics register for lane 1
Continues for all 12 lanes (0-11) up to address 0x0A2E
