0x0880
to
0x08AE
statistics
counters
RX CRC32 Error Statistics Registers – RO
0x0880 Bit 15:0 – returns the value contained in bits 15-0 (LSB) of RX
CRC32 Error Statistics register for lane 0
0x0882 Bit 15:0 – returns the value contained in bits 31-16 (MSB) of
RX CRC32 Error Statistics register for lane 0
0x0884 Bit 15:0 – returns the value contained in bits 15-0 (LSB) of RX
CRC32 Error LSB Statistics register for lane 1
0x0886 Bit 15:0 – returns the value contained in bits 31-16 (MSB) of
RX CRC32 Error Statistics register for lane 1
Continues for all 12 lanes (0-11) up to address 0x08AE
0x0900
to
0x092E
statistics
counters
RX Word Boundary Synchronization Statistics Registers – RO
0x0900 Bit 15:0 – returns the value contained in bits 15-0 (LSB) of RX
Word Boundary Synchronization Statistics register for lane 0
0x0902 Bit 15:0 – returns the value contained in bits 31-16 (MSB) of
RX Word Boundary Synchronization Statistics register for lane 0
0x0904 Bit 15:0 – returns the value contained in bits 15-0 (LSB) of RX
Word Boundary Synchronization Statistics register for lane 1
0x0906 Bit 15:0 – returns the value contained in bits 31-16 (MSB) of
RX Word Boundary Synchronization Statistics register for lane 1
Continues for all 12 lanes (0-11) up to address 0x092E
