Chapter 4 Basic Operation
Emulsion side of film
Base side of film
Fi^re 4.3 Inserting the emulsion side of the film facing the top of Coolscan.
Slide Mounts
Both positive and negative film can be cut and mounted. These mounts can vary
in thickness and material. Typical 35mm slide mounts are composed of either catd-
board or plastic, and may or may not use glass. Coolscan can accept slide mounts that
are up to 50mm wide by 3mm thick.
The mounted film is assumed to be at the centet of the slide mount, as shown in
Figure 4.4. The film will be centered in the scanner’s focal field without user interven­
tion.
Figure 4.4 The film position concerning the center of the slide frame.
Nikon
Coolscan Installation Guide for Macintosh Page 35
