CONNECTIONS
At first, decide the outline of the connection among this unit, your TV set and the amplifier, etc. It is necessary to set the setup menu of
this unit according to the connection.
Before connection, identify the type of your audio equipment or of the TV set referring to the following chart. Then decide the connection
and the setup menu according to the types.
Audio system to be connected Input jack of equipment to be
connected to the DVD player
Referring
Letter
None (only the television is connected) See ®.
A stereo system or an amplitier Digital (optical) input jack See B.
Analog audio input jacks (L/R) See lc|.
An AV amplifier equipped with Dolby Digital
decoder or a Dolby Digital decoder
Digital (optical) input jack See El.
Analog audio input jacks (L/R) SeeE.
An AV amplifier equipped with DTS decoder
or a DTS decoder
Digital (optical) input jack See B.
Before making connections
• Connect the AC cords of the unit and externai equipment at
the end, after finishing the other connections.
• Insert the plugs completely into the jacks. Loose connections
may produce a humming sound or other noise interference.
• Refer to the instructions for the connected equipment.
CAUTiON
Do not select “Dolby Digital” in the “Audio Output Setting” when
connecting to an AV amplifier not equipped with a Dolby Digital
decoder (with an optical connecting cord).
Merely attempting to play a DVD may cause a high level of noise
which could be harmful to your ears and damage the speakers. In
such a case, be sure to select “Down Mix PCM” in the “Digital
Stream”.
