Specifications
MD recorder section
System
Disc
Laser:
Wavelength:
Laser diode properties
Revolutions
Error correction
Sampling frequency
Modulation system
Number of channels
Frequency response
Wow and flutter
Inputs
MiniDisc digital audio system
MiniDisc
Semiconductor laser
780—790nm
Material: GaAIAs
Emission duration: continuous
Laser output: less than 44.6 pW
(This output is the value measured
at a distance of 200 mm from the
lens surface on the optical pick-up
block.)
400 rpm to 900 rpm (CLV)
Advanced Cross Interleave Reed
Solomon Code (ACIRC)
44.1 kHz
EFM (EighHo-Fourteen Modulation)
2 stereo channels
5 to 20,000 Hz ±0.5 dB
Below measurable limit
Jack type
Input
impedance Rated
input Minimum
input
MIC
Stereo
mini-jack
600 ohms 0.8 mVrms 0.3 mVrms
LINE IN
Phono
jack
More than
47 kilohms
500 mVrms 158 mVrms
DIGITAL
IN Square
optical
connector
jack
Optical
wave
lenghth
660 nm
- —
Outputs
Jack type Rated output
Load
impedance
HEAD­
PHONES Stereo mini-
jack
28 mW 32 ohms
LiNE OUT
Phono
jack
2 Vrms at a
toad
impedance of
50 kilohms
More than
10 kilohms
DIGITAL
OUT
Square optical
connector jack -18 dBm Optical
wave
lenghth
660 nm
General
Power requirements
Power consumption
Dimensions
Mass
120 V A C . 60 Hz
22 W
Approx. 225 X 75 X 285 mm (w/h/d)
(8Ve X 3 X 11’/4 inches)
incl. projecting parts
Approx. 2.9 kg
(6 lb 6 oz)
Supplied accessories
• Remote commander RM-D1M (1)
• Sony SUM-3 (NS) batteries (2)
• Audio connecting cords (pin-jack x 2 pin-jack x 2) (2)
• Audio (AU) bus cable (1)
• Recordable MD: MDW-60 (1)
Optional accessories
• Optical cable: POC-15SP
• Recordable MDs: MDW-60 (60 min.), MDW-74 (74 min.)
(available spring 1993)
Design and specifications are subject to change without
notice.
