Removing and Installing Parts
77
3 With the cover release latch pulled back, grip the sides of the cover, then pivot the top of the cover up
and away from the computer.
4 Slide the cover forward and up to remove it from the hinge slots, then set it aside in a secure and
protected location.
1 computer cover 2 cover release latch 3 cover hinge tabs
4 stabilizing feet (closed)
2
3
1
4
