Troubleshooting 41
2 Check Virtual Disks and determine if the bootable Non-RAID virtual
disk is no longer in the first position.
3 Use the Swap Two Virtual Disks option to swap the virtual disks and place
the bootable Non-RAID virtual disk in the first position of the Virtual
Disks field.
The PERC BIOS Configuration Option does not Display
The PERC S110 mode is Set Incorrectly in the System BIOS
See "Controller mode is set Incorrectly at System Setup" on page 39 for the correct
SATA Setting.
Warning Messages: Dell Inc. PERC S110 Adapter
BIOS Screen
The Dell Inc. PERC S110 Controller BIOS screen is one of the first screens
to appear during your system’s boot sequence. If the system’s virtual disks
were in Normal or Ready status before a system boot, the boot sequence
continues normally to the Microsoft Windows Server 2008 operating system.
But, if a virtual disk is in Degraded or Failed status, or if specific options in
the Controller Options field were changed previously at the PERC BIOS
Configuration Utility, the following warning messages appear during the boot
sequence. For other issues, see "Other Errors Appearing on the BIOS" on
page 44.
WARNING: Found Virtual Disks that are Degraded
This warning message appears when at least one virtual disk is in a Degraded
state and Pause if Degraded is set to ON at the PERC BIOS Configuration
Utility.
The following message appears after the warning is displayed:
--- Press to continue, or to enter
setup ---
Press to allow the operating system to continue with the boot
sequence, or press to enter into the PERC BIOS
Configuration Utility to investigate the cause of the Degraded virtual disk.
