20 About Your System
4 PCIe slot 4 PCIe x8-link Gen 2 expansion slot (full-
height, 24.13-cm [9.5"] length)
5 power supply 1 (PS1) 870-W or 570-W power supply
6 power supply 2 (PS2) 870-W or 570-W power supply
7 system identification
button
The identification buttons on the front
and back panels can be used to locate a
particular system within a rack. When
one of these buttons is pushed, the
LCD panel on the front and the system
status indicator on the back flash blue
until one of the buttons is pushed
again.
8 system status indicator Provides a power on indicator for the
back of the system.
9 system status indicator
connector
Connector for attaching a system
indicator extension cable that is used
on a cable management arm.
10 Ethernet connectors
(4)
Integrated 10/100/1000 NIC connectors
11 USB connectors (2) Connects USB devices to the system.
The ports are USB 2.0-complaint.
12 video connector Connects a VGA display to the system.
13 serial connector Connects a serial device to the system.
14 iDRAC6 Enterprise
port (optional)
Dedicated management port for the
optional iDRAC6 Enterprise card.
15 VFlash media slot
(optional)
Connects an external SD memory card
for the optional iDRAC6 Enterprise
card.
Item Indicator, Button, or
Connector Icon Description
