102 Installing System Components
Figure 3-11. Removing or Installing a NIC Hardware Key
5 Close the system. See "Closing the System" on page 83.
6 Reconnect the system to the electrical outlet and turn on the system and
attached peripherals.
Cooling Shroud
The system provides a cooling shroud that directs airflow from the cooling
fans over the system processor and memory module(s).
CAUTION: Many repairs may only be done by a certified service technician.
You should only perform troubleshooting and simple repairs as authorized in
your product documentation, or as directed by the online or telephone service
and support team. Damage due to servicing that is not authorized by Dell is not
covered by your warranty. Read and follow the safety instructions that came
with the product.
WARNING: The memory modules are hot to the touch for some time after the
system has been powered down. Allow the memory modules to cool before
handling them.
1 NIC hardware key 2 ISCSI_KEY connector
1
2
