Troubleshooting Your System 155
4
Troubleshooting Your System
Safety First—For You and Your System
CAUTION: Many repairs may only be done by a certified service technician.
You should only perform troubleshooting and simple repairs as authorized in
your product documentation, or as directed by the online or telephone service
and support team. Damage due to servicing that is not authorized by Dell is not
covered by your warranty. Read and follow the safety instructions that came
with the product.
Troubleshooting System Startup Failure
If your system halts during startup prior to video imaging or LCD messaging,
especially after installing an operating system or reconfiguring your system’s
hardware, check for the following conditions.
• If you boot the system in BIOS boot mode after installing an operating
system in UEFI boot mode, the system will hang. The reverse is also true.
You must boot to the same boot mode in which you installed the operating
system. See "Using the System Setup Program and UEFI Boot Manager"
on page 57.
• Invalid memory configurations could cause the system to halt at startup
without any video output. See "System Memory" on page 130.
For all other startup issues, note the LCD panel messages and any system
messages that appear on-screen. See "LCD Status Messages" on page 23 and
"System Messages" on page 38 for more information.
Troubleshooting External Connections
Ensure that all external cables are securely attached to the external
connectors on your system before troubleshooting any external devices.
See Figure 1-1 and Figure 1-4 for the front- and back-panel connectors on
your system.
