Jumpers and Connectors

30 DIMM 13

Memory module connector, slot 13

31 DIMM 14

Memory module connector, slot 14

32 DIMM 15

Memory module connector, slot 15

33 DIMM 16

Memory module connector, slot 16

34 CPU 2

Processor 2 connector

35 DIMM 5

Memory module connector, slot 5

36 DIMM 6

Memory module connector, slot 6

37 DIMM 7

Memory module connector, slot 7

38 DIMM 8

Memory module connector, slot 8

39 BATTERY

Connector for the 3.0-V coin battery

40 CONTROL_PANEL

Control panel cable connector

Table 6-2.

System Board Connectors (continued)

Connector Label

Description

NOTE:

For the full name of an abbreviation or acronym used in this table, see the "Glossary" on page 155.
