The side of the chassis. see figure 3-28 – Dell PowerEdge 6950 User Manual
Page 91
Installing System Components
91
Figure 3-28.
Securing the Power Distribution Cable Harness
12 Remove the RAID battery compartment:
a
Lift the snap lever and gently pull the RAID battery compartment straight up. See Figure 3-29.
b
Lift the battery compartment away from the side of the chassis.
1
power distribution cable
harness
2
Velcro pads (2)
1
2
