Jumpers and Connectors
125
Table 6-2. System Board Connectors
Connector Label Description
1 PSWD_EN Password jumper
2 NVRAM_CLR Configuration jumper
3 SLOT 7 x4 PCIe expansion card connector
4 SLOT 6 x4 PCIe expansion card connector
5 SLOT 5 x4 PCIe expansion card connector
6 SLOT 4 x8 PCIe expansion card connector
7 SLOT 3 x8 PCIe expansion card connector
8 SLOT 2 x4 PCIe expansion card connector
9 SLOT 1 x4 PCIe expansion card connector
10 INTERNAL_STORAGE SAS controller card connector
11 RAC_CONN remote access card (RAC) connector
12 RAC_CONN1 Connector for the 40-pin RAC cable
13 RAC_CONN2 Connector for the 50-pin RAC cable
14 CPU 1 Processor 1 connector
15 DIMM 1 Memory module connector, slot 1
16 DIMM 2 Memory module connector, slot 2
17 DIMM 3 Memory module connector, slot 3
18 DIMM 4 Memory module connector, slot 4
19 DIMM 9 Memory module connector, slot 9
20 DIMM 10 Memory module connector, slot 10
21 DIMM 11 Memory module connector, slot 11
22 DIMM 12 Memory module connector, slot 12
23 12V 12 V power connector
24 PWR_3.3Stby_Cntrl Power distribution board signal connector
25 CPU 3 Processor 3 connector
26 VRM 3 Voltage regulator module (VRM) 3 connector
27 VRM 4 VRM 4 connector
28 CPU 4 Processor 4 connector
29 INTRUSION Intrusion switch connector
NOTE:
For the full name of an abbreviation or acronym used in this table, see the "Glossary" on page 155.
