Installing System Components
3 Open the system. See "Opening the System" on page 46.
4 If you are adding a new card, select the appropriate expansion card slot. See "Expansion Card
Installation Guidelines" on page 52.
5 Open the expansion-card retainer and remove the filler bracket. See Figure 3-8.
6 Install the expansion card:
a Holding the card by its edges, position the card so that the card-edge connector aligns with the
expansion-card connector on the system board.
NOTICE:
If you are installing a SAS RAID controller card, do not press on the memory module when installing the
card.
b Insert the card-edge connector firmly into the expansion-card connector until the card is fully
seated.
c Close the expansion-card retainer. See Figure 3-8.
