Using the System Setup Program | 61

Option

Description

OnChip SATA Channel
(Enabled default)

Select this item to enable or disable Onboard SATA
controller.

OnChip SATA Type
(Native IDE default)

Native IDE: Native mode.
AMD_AHCI: Use AMD AHCI option ROM.
IDE->AMD_AHCI: No AHCI option ROM, use
AMD AHCI driver (need load driver when install OS,
windows 2008 R2 had native support.)

RAID: Use RAID option ROM.

SATA IDE Combined Mode
(Enabled default)

Two SATA (Port 4 and Port 5) share one IDE channel
(could be either Primary or Secondary channel) from
IDE (PATA) controller.

Hard Disk Write Protect
(Disabled default)

Select this item to disable/enable device write
protection. This will be effective only if device is
accessed through BIOS.
