164 | Installing System Components
1 DIMM A1_CHA 2 DIMM A2_CHA
3 DIMM A3_CHB 4 DIMM A4_CHB
5 DIMM A5_CHC 6 DIMM A6_CHC
7 DIMM A7_CHD 8 DIMM A8_CHD
9 DIMM C1_CHA 10 DIMM C2_CHA
11 DIMM C3_CHB 12 DIMM C4_CHB
13 DIMM C5_CHC 14 DIMM C6_CHC
15 DIMM C7_CHD 16 DIMM C8_CHD
17 DIMM D8_CHD 18 DIMM D7_CHD
19 DIMM D6_CHC 20 DIMM D5_CHC
21 DIMM D4_CHB 22 DIMM D3_CHB
23 DIMM D2_CHA 24 DIMM D1_CHA
25 DIMM B8_CHD 26 DIMM B7_CHD
27 DIMM B6_CHC 28 DIMM B5_CHC
29 DIMM B4_CHB 30 DIMM B3_CHB
31 DIMM B2_CHA 32 DIMM B1_CHA
NOTE: For the thermal concern, each DIMM socket needs to be installed with a
real or dummy DIMM.
