92 | Using the System Setup Program
Option Description
Save Customized Defaults Saves the changes as User Defaults.
Load Customized Defaults Loads the User Defaults to all the setup options.
Command Line Interface for Setup Options
The options of SETUP menu allow users to control by system configuration
utility (syscfg). The utility is included in Dell OpenManage Deployment
Toolkit (DTK).
Users can use the utility as following:
• To change the SETUP option by D4 token:
./syscfg –t=D4_token_id
(Example: ./syscfg -t=0x002D to enable NIC1 Option ROM)
• To check token activity status:
./syscfg -- istokenactive=D4_token_id
(Example: ./syscfg --istokenactive=0x002D to check the token activity
status of NIC1 Option ROM)
• To change the SETUP option through BMC memory directly:
./impitool raw
(Example: ./impitool raw 0xc 1 1 3 10 106 42 120 to set IP address of
BMC LAN port as 10.106.42.120)
Table 2-1. The D4 Token Table
Token Setup Option Description
002D NIC1 Option ROM
Enable the system’s primary embedded
network interface controller (full function),
including its PXE boot-ROM.
002E NIC Function Support
Disable the system’s onboard network
interface controller.
0051 BOOTSEQ_DSKT
For the next system boot, set the IPL
priority to: diskette, hard drive, IDE
CD-ROM, option ROMs (if the devices are
available)
0052 BOOTSEQ_HDONLY
For the next system boot, set the IPL
priority to: hard drive then option
