Jumpers and Connectors
157
Jumpers and Connectors
This section provides specific information about the system jumpers and
describes the connectors on the various boards in the system.
System Board Jumpers
Figure 6-1 shows the location of the configuration jumpers on the system
board. Table 6-1 lists the jumper settings.
System Board Connectors
See Figure 6-1 and Table 6-2 for the location and description of the system
board connectors.
Table 6-1. System Board Jumper Settings
Jumper Setting Description
PWRD_EN (default) The password feature is enabled.
The password feature is disabled.
NVRAM_CLR (default) The configuration settings in NVRAM are
retained at system boot.
The configuration settings in NVRAM are
cleared at next system boot.
