Using the ISA Configuration Utility: Dell OptiPlex GX1 and GX1p Midsize Managed PC Systems
file:///C|/infodev/2013/eDoc/OpGX1/SIG/utility.htm[2/21/2013 12:07:21 PM]
the following steps:
1. If it is not already installed, install the Plug and Play or PCI expansion card. Then turn on the
system.
Complete steps 2 through 10 in " Installing an Expansion Card ."
2. Start the ICU.
See " Starting the ICU ."
3. Select Locking Enabled from the Advanced menu in the ICU window.
A check mark next to Locking Enabled signifies that the feature is active; a Lock button appears on the
tool bar.
4. Select the Plug and Play or PCI expansion card that you want to lock or unlock from the Cards
Configured in System list.
5. Click Lock or select Lock/Unlock Card from the Advanced menu.
Both options toggle the lock state of the selected card.
Locking and Unlocking Configuration Resources
You can also lock and unlock individual resources for a Plug and Play or PCI expansion card. To do so,
perform the following steps:
1. If it is not already installed, install the Plug and Play or PCI expansion card. Then turn on the
system.
Complete steps 2 through 10 in " Installing an Expansion Card ."
2. Start the ICU.
See " Starting the ICU ."
3. Select Locking Enabled from the Advanced menu in the ICU window.
A check mark next to Locking Enabled signifies that the feature is active; a Lock button appears on the
tool bar.
4. Select the Plug and Play or PCI expansion card that you want to lock or unlock from the Cards
Configured in System list.
5. Click Modify or select Modify Card from the Configure menu.
6. From the Card Configuration dialog box, select the function you want to lock or unlock.
7. Click Settings.
8. Modify the resource setting and/or resources offered on the Configuration Settings dialog box,
if necessary.
