Figure 16, Figure 17 – Dell Metered PDU LCD User Manual
Page 26
26
|
Installation
Side-Mounted Strain Relief Bracket (Optional)
48U
(6) 20A Circuit Breakers
Output Receptacles
(48) IEC 320-C13; 10A
IEC60309-60A
(Waterproof - IP 67)
460P9W
Figure 16. DELLM0006
48U
(6) 20A Circuit Breakers
Output Receptacles
(48) IEC 320-C13; 10A
IEC60309-32A
(Splash resistant - IP 44)
532P6S
Side-Mounted Strain Relief Bracket (Optional)
Figure 17. DELLM0007
