Specifications
Dell Precision™ M2300 User's Guide
NOTE: Offerings may vary by region. For more information regarding the configuration of your computer, click Start® Help and Support and select the
option to view information about your computer.
Processor
Processor type Intel® Core™ 2 Duo Processors
L1 cache 32 KB per instruction, 32 KB data cache per core
L2 cache up to 4 MB
External bus frequency 800 MHz
System Information
System chipset Intel PM965 Express chipset
Data bus width 64 bits
DRAM bus width dual-channel (2) 64-bit buses
Processor address bus width 36 bits
Flash EPROM 2 MB
Graphics bus internal or PCI-E graphics (PEG)
PCI bus 32 bits
PC Card/ExpressCard
CardBus controller 02Micro OZ711EZ1
PC Card connector one (supports one Type I or Type II card)
Cards supported PC Card: 3.3 V and 5 V
ExpressCard: 34 mm with adapter
PC Card connector size 80 pins
PCI-E Card
Flash Cache Module (FCM) 1 GB
Memory
Memory module connector two user-accessible SODIMM sockets
Memory module capacities 512 MB, 1 GB, and 2 GB
Memory type DDR2 SODIMM
Minimum memory 1 GB
Maximum memory 4 GB
Smart Card
Read/write capabilities reads and writes to all ISO 7816 1/2/3/4
microprocessor cards (T=0, T=1)
Cards supported 3 V and 5 V
Program technology supported Java cards
Interface speed 9600–115,200 BPS
EMV level level 1 certified
WHQL certification PC/SC
Compatibility compatible within a PKI environment
Insert/eject cycles certified for up to 100,000 cycles
