1 power connector
(J3J1)
10 battery socket (XBT9E1)
2 floppy drive
connector (J4J1)
11 front-panel audio connector
(J9C2)
3 CD/DVD drive
connector (J6J1)
12 CD/DVD audio connector
(J9C1)
4 hard-drive connector
(J6J2)
13 PCI card slots (3) (PCI1, PCI2,
PCI3)
5 control panel
connector (J7J2)
14 modem telephony/internal
chassis speaker connector
6 standby power light
(AUX_PWR)
15 processor power connector
(J5B1)
7 password jumper
(CLEAR PASSWORD)
16 processor connector (J2E1)
8 serial ATA connector
(J8G1)
17 fan connector (J1F1)
9 front-panel
connector (J9G1)
18 memory module connectors
(DIMMs 1 and 2)
