System board components, Inside your computer – Dell OptiPlex 170L User Manual
Page 98
Inside Your Computer
System Board Components
CAUTION:
Before you begin this procedure, follow the safety instructions in the Product Information Guide.
CAUTION:
To guard against electrical shock, always unplug your computer from the electrical outlet before opening the computer cover.
1 CD drive
5 primary hard drive
2 secondary CD drive
6 power supply
3 optional floppy drive 7 system board
4 secondary hard drive
