Installing System Components 65
Figure 3-4. Removing a Hot-Plug Hard Drive
4 Slide the hard drive out until it is free of the drive bay.
5 If you do not replace the hard drive, insert a drive blank in the vacated
drive bay. See "Installing a Drive Blank" on page 63".
Installing a Hot-Plug Hard Drive
NOTICE: When installing a hard drive, ensure that the adjacent drives are fully
installed. Inserting a hard drive carrier and attempting to lock its handle next to a
partially installed carrier can damage the partially installed carrier's shield spring
and make it unusable.
NOTICE: Not all operating systems support hot-plug drive installation. See the
documentation supplied with your operating system.
1 activity and fault indicators 2 drive carrier release handle
3 hard drive
2 3
1
