Installing System Components 75
Figure 3-8. Removing a Back System Fan Housing
Installing a Back System Fan Housing
CAUTION: Only trained service technicians are authorized to remove the system
cover and access any of the components inside the system. See your Product
Information Guide for complete information about safety precautions, working
inside the computer, and protecting against electrostatic discharge.
1 Ensure power is removed.
2 Open the system. See "Removing the Top Cover" on page 60.
3 Align fan housing guides with frame.
1 Fan housing latch 2 Fan housing
3 Fan loop handle 4 Location of fan housing
3
2
1
4
