Jumpers and Connectors 159
Figure 6-4. SAS Backplane Connectors: 3.5-inch x5 Option (Front)
1 SATA_MODULE 2 CDROM
3 Fans (right) 4 Hard disk 4
5 Hard disk 3 6 Fans (left)
7 Hard disk 2 8 Hard disk 1
9 Hard disk 0 10 Control panel
10
9
8
7
5
6
4
1 2 3
