Audio-Jack Board Removal: Dell™ Inspiron™ 3500 Portable Computer

To remove the audio jack board, see the exploded view of the

base assembly

and perform the following steps:

1. Remove the

display assembly

2. Remove the

keyboard

3. Remove the

palmrest assembly

4. Remove the

system board rails

5. Remove the

DC/DC board

6. Disconnect the

speaker

cables.

7. Remove the

system board

8. Remove the audio jack shielding that covers the audio jacks on three sides. Note that the shielding wraps around and goes beneath the system board and the

EMI pan, not between the board and the pan.

9. Lift the audio jack board off of connectors J16 and J11 on the system board.

When you install the audio jack board, it is helpful to move the PC Card latches out of the way. Put pressure only on the areas where the connectors on the audio jack
board and on the system board fit together. Pressing on other areas may bend the board and break connections.
