PC Card Cage Removal: Dell™ Inspiron™ 3500 Portable Computer

The PC Card cage is supplied as a part of the system board assembly. However, if only the PC Card cage needs replacement, use this procedure to remove and
replace the PC Card cage. You do not need to remove the entire system board.

To remove the PC Card cage, see the exploded view of the

base assembly

and perform the following steps:

1. Remove the

display assembly

2. Remove the

keyboard

3. Remove the

palmrest assembly

4. Remove the

system board rails

5. Remove the

LVDS board

modem card

(if present), and

video board

6. Remove the four 14-mm screws securing the PC Card cage to the system board.
7. Remove the PC Card cage.

When you install the PC Card cage, ensure that the modem cable is routed correctly and is not pinched by the cage.

Type of Screw Torque

PNH 2 x 14 (4) 1.5–1.8 kgf-cm
