Dell Inspiron 3500 - Manual (Page 127)

PC Cards
Memory
Connectors
Audio
Microprocessor address bus width 32 bits
Flash EPROM 4 Mbits
Bus architecture:
PCI 33-MHz local bus frequency
32-bit data bus width
AGP 66-MHz local bus frequency
32-bit data bus width
ISA 8.33-MHz bus frequency
16-bit data bus width
PCI controller Texas Instruments PCI1220 CardBus controller
PC Card connectors two (supports a single type III card or two type I or II cards)
Cards supported 3.3- and 5-V cards
PC Card connector size 68 pins
Data width (maximum) 32 bits
Architecture SDRAM
Memory module capacities 32-, 64-, and 128-MB memory module
Standard RAM (13.3-inch display) 32 MB (one 32-MB SODIMM that is installed in one of the two
memory expansion connectors)
Standard RAM (14.1-inch display) 64 MB (one 64-MB SODIMM that is installed in one of the two
memory expansion connectors)
Maximum RAM 256 MB
Memory access time/clock frequency 66 MHz
BIOS address F000:0000
Serial 9-pin connector; 16550-compatible, 16-byte buffer
Parallel 25-hole connector; normal (unidirectional), bidirectional, EPP
1.9 or ECP
Monitor 15-hole connector
PS/2 keyboard/mouse 6-hole mini-DIN connector
Infrared infrared port
Docking connector 240 pins
Audio microphone, headphones/speakers, line-in
USB 4-pin connector
RJ11 RJ11 modem port (optional, not available in all regions)
Audio type Sound Blaster Pro-compatible voice and music functions,
software wavetable
Audio controller NeoMagic NM3298
Conversion 16 bit (stereo analog-to-digital and digital-to-analog)
FM music synthesizer 20-voice, 72-operator
Interfaces:
Internal ISA bus, microphone, dual stereo speakers
External microphone, headphones, and line-in jacks
