DC/DC Board Removal: Dell™ Inspiron™ 3500 Portable Computer

To remove the DC/DC board, see the exploded view of the

base assembly

and perform the following steps:

1. Remove the

display assembly

2. Remove the

keyboard

3. Remove the

palmrest assembly

4. Remove the

system board rails

5. Remove the 14-mm screw.
6. Gently lift the DC/DC board off of the connector on the system board.

When you install the board, put pressure only on the areas where the connectors on the DC/DC board and on the system board fit together. Pressing on other areas
may flex the board and break connections.

Type of Screw

Torque

FPH 2.5 x 14 (1) 3.0–3.5 kgf-cm
