Dell Inspiron 3500 User Manual
Page 117
Speaker Removal: Dell™ Inspiron™ 3500 Portable Computer
To remove the speakers, see the exploded view of the
base assembly
and perform the following steps:
1. Remove the
display assembly
.
2. Remove the
keyboard
.
3. Remove the
palmrest assembly
.
4. Remove the
system board rails
.
5. Remove the
DC/DC board
.
6. Disconnect the left speaker cable from connector J13 on the system board.
7. Disconnect the right speaker cable from connector J15 on the system board.
8. Lift the speakers and cables out of the bottom plastic.
NOTE: The left and right speakers are interchangeable. Note the routing of the speaker cables through the plastic routing ribs for installation.
