84 Configuring and Managing RAID
down-arrow
key
Use the down-arrow key to move to the lower menu
items within a menu or to a lower level menu. You
can also use the down-arrow key to open a menu list
in a popup window, such as the stripe element size
menu, and select a setting. Word wrap is supported.
Virtual Disk 1
Virtual Disk 4
After you highlight a menu item, press to
select that item. An options menu for the menu item
opens. It applies to only certain menu items, such as
Virtual Disk #. In a list of options for that item,
such as the write policy for a virtual disk, highlight a
setting, such as Write-Through, and press
to select it.
Select Add New
VD and press
to
create a new
virtual disk.
After you expand a pop-up window, press to
close the window. You can continue to press
to exit the BIOS Configuration Utility.
Press to
return to the VD
Mgmt screen.
Press to move the cursor to the next control
on a dialog box or page.
Press to
move the cursor
to the next
parameter you
want to change.
Press to move the cursor to the
previous control on a dialog or page.
Press
to move the
cursor from Sort
By to the
previously
selected PD in
the PD Mgmt
screen
Press to move to the next menu screen
among the main menu screens: VD Mgmt, PD
Mgmt, Ctrl Mgmt, and Foreign View.
Press
on
the VD Mgmt
screen to move to
the PD Mgmt
screen.
Table 6-1. Menu Navigation Keys (continued)
Notation Meaning and Use Example
