Hard-Disk Drive Assembly
Figure 5. Hard-Disk Drive Assembly Removal
NOTICE: To avoid damaging the system board, you must remove the main battery before you service the computer.
NOTICE: The hard-disk drive is very sensitive to shock. Handle the assembly by its edges (do not squeeze the top of the hard-disk
drive case), and avoid dropping it.
NOTICE: Make sure that the work surface is clean to prevent scratching the computer cover.
1. Turn the computer over, and remove the two M3 x 3-mm screws from the bottom of the hard-disk drive door (see Figure 5).
The hard-disk drive is located on the right side of the computer.
2. Pull the drive out of the computer.
Keyboard Bezel
1 Keyboard bezel
2 Right hinge cover
3 Hard-disk drive
4 Modem
5 System board assembly
6 Fan
7 Docking doors (not supported)
8 Bottom case assembly
9 Battery
10 Speaker
11 Audio I/O port cover
12 Audio EMI shield
13 Palmrest assembly
14 Keyboard
15 Left hinge cover
16 Display assembly
1 Hard-disk drive
2 M3 x 3-mm screws (2)
