Modem connector, Nic connector, External media options – Dell Inspiron 2000 User Manual
Page 14: External media bay, External media bay connector
Modem Connector
You can connect a telephone line to the integrated modem through the RJ11 modem connector on the back of the computer.
on your computer. Do not plug a telephone line into the NIC connector.
NIC Connector
You can connect to the integrated network interface controller (NIC) through the RJ45 connector on the back of the computer.
on your computer. Do not plug a telephone line into the NIC connector.
External Media Options
You can connect
external media options
such CD-ROM, DVD-ROM, SuperDisk LS-120, and diskette drives to the external media bay connector.
Back to Contents Page
