Removing and Replacing Parts: Dell™ Inspiron™ 2000 System Reference
NOTICE: Only a certified service technician should perform the procedures for removing and replacing parts. The warranty on the
computer becomes void if anyone other than a certified technician performs these procedures.
Overview
This section provides instructions for removing and replacing field-replaceable components, assemblies, and subassemblies in your Dell Inspiron
2000 portable computer. Unless otherwise noted, each procedure in this manual assumes the following conditions:
l
The computer and any attached peripherals are turned off, and the peripherals are disconnected from the
I/O panel
on the back and right
side of the computer.
l
A part can be replaced by performing the removal procedure in reverse order unless otherwise noted.
When the display assembly is open nearly 180 degrees, use a book or something similar to support it. The angle of the display assembly with
respect to the bottom case should never exceed 180 degrees. Also, when performing the procedures in this manual, the locations or directions
relative to the computer are as shown in Figure 1 unless otherwise specified.
Figure 1. Computer Orientation
Preparing to Work Inside Your Computer
