Edge Lighting Regal LED - Manual (Page 2)

2
WIRE NUT
JUNCTION BOX
6
5
LED DRIVER 5:
junction box.
6:
Connect the black LED driver wire to the HOT wire in the
Connect the white LED driver wire to the NEUTRAL wire
in the junction box. Place wire connections and LED driver
into the junction box.
#8-32 SCREW
CROSSBAR ASSEMBLY
JUNCTION BOX HOLE
8
7
8
7:
hole.
8: Mount the crossbar o the junction box holes with
the provided two #8-32 screws.
Feed the power wires through the crossbar assembly center
assembly t
9:
using wire nuts. Connect each fixture wire to one red LED driver wire
10:
11: Secure the fixture to the crossbar studs using the two hex
nuts and lock washers.
Slide the canopy holes onto the threaded crossbar studs
9
12:
fixture. Slide the glass panels into top and bottom of slots of the
13: Replace the front cover.
14: Replace the thumb nuts onto the mounting screws and
tighten to secure front cover in place.
9
11
11
10
12
13
14
NOTE: Make sure the power to the electrical box is off before
continuing.
STUD
HEX NUT/
LOCK
WASHERS
WALL
WALL
WALL
WALL
GLASS PANEL
FIXTURE
WIRE NUT
WIRE NUT
THUMB NUTS
FRONT COVER
14
