Edge Lighting Regal User Manual
Page 3
H
FIXTURE BODY
12: Insert the glass diffusers between the fixture body and
inner bracket.
14:
threaded rods to secure the cover in place.
Replace the cover and tighten the two thumb screws to the
J
THUMB SCREW
14
COVER
FIXTURE BODY
14
THREADED RODS
I
SPRING
CLIP
REFLECTOR
FIXTURE
INNER
BRACKET
SPRING CLIP
13
13
13
13: Align and insert the reflector ends into the inner bracket
and secure it in place by replacing the spring clips.
GLASS DIFFUSER
12
12
3
