Replacing the Lamp
1:
2: Loosen and r
.
3: Screw
Reach the burnt lamp through the crystals.
emove the burnt lamp
the new lamp completely into the socket holes.
FABRIC SHADE TAB
J
SUPPORT
FRAME ARM
13: Slide the fabric shade from the bottom of the chandelier
up. Align and set the shade tab holes onto the support arm
ends.
K
SOCKET
LAMP
13
13
3
