FIXTURE HEAD
2
2
E
#4-40 SET
SCREW
0.05 ALLEN
WRENCH
3
4
CIRCUIT #1 CIRCUIT #2
1
2
N
1
2
N
3: To power the fixture from circuit #1, top and bottom
(neutral) rails, tighten the #4-40 set screw on top of the
housing with the 0.05 Allen wrench. Make sure this set
screw connection is very tight.
4: To power the fixture from circuit #2, middle and bottom
(neutral) rails, remove the #4-40 set screw from top of the
housing and tighten it into the side threaded hole with the
0.05 Allen wrench. Make sure this set screw connection
is very tight.
NOTE:
set screw to select a circuit on the Monorail 2 Circuit connector.
To avoid shorting the system, do not use more than one
NOTE: Do not load either circuit over the maximum system
rating.
FAST JACK CANOPY
CONNECTOR
FAST JACK FIXTURE
CONNECTOR
F
1
1: Use fingers to tighten the Fast Jack fixture connector into
the Fast Jack canopy connector.
2:
light. Rotate the fixture head to properly wash the wall with
G
Install the Fixture to Fast Jack LED Canopy (FJP-2SQ-LED_,
FJP-4SQ-LED_, FJP-4RD-LED_)
NOTE: The Cody 2 consumes 6 watts and contains integrated
LED lamps which are rated for 50,000 hours.
