CAUTION: To reduce risk of a burn or electrical shock during
lamping, disconnect the power to the fixture.
4
Install the Lamp
1: Slightly loosen the three M4 set screws (Do Not Remove)
with the 2mm Allen wrench provided, to remove the glass
shade.
I
SOCKET
1
J
LAMP
SOCKET
2
3: Align the socket assembly set screws to the glass shade
hole. While holding the glass shade in place, secure it by
tightening the three M4 set screws with the provided 2mm
Allen wrench.
K
GLASS SHADE
3
GLASS SHADE
2: Push the lamp pins completely into the socket holes.
CAUTION: To reduce risk of a burn or electrical shock during
lamping, disconnect the power to the fixture.
NOTE: Use only fingers and a soft cloth to install the lamps.
Use MAX 20 Watt, Type Bi-Pin Halogen Lamp.
M4 SET SCREW 4MM ALLEN
WRENCH
SOCKET
