User Guide for the SIP-T48G IP Phone
2
Hardware component instructions of the SIP-T48G IP phone are:
Item Description
① Power Indicator LED Indicates phone power and some feature statuses.
② Touch Screen
Shows information about calls, messages, soft keys,
time, date and other relevant data:
• Call information—caller ID, call duration
• Icons (for example, )
• Missed call text or second incoming caller information
• Prompt text (for example, “Saving file…”)
• Time and date
③ HEADSET Key Toggles and indicates the headset mode.
④ MUTE Key Toggles and indicates mute feature.
⑤ HOLD Key Places a call on hold or resumes a held call.
⑥ TRANSFER Key Transfers a call to another party.
⑦ Speakerphone Key Toggles the hands-free speakerphone mode.
⑧ MESSAGE Key Accesses voice messages.
⑨ REDIAL Key Redials a previously dialed number.
⑩
Position the cursor.
Enable or disable fields.
Turn pages or scroll through values for a field.
Scroll through items.
Confirms actions or answers incoming calls.
Cancels actions or rejects incoming calls.
⑪ Volume Key
Adjusts the volume of the handset, headset, speaker and
ringer.
⑫ Keypad
Provides the digits, letters and special characters in
context-sensitive applications.
Icons appearing on the touch screen are described in the following table:
Icons Description
Network is unavailable
Registered successfully
Register failed
