Displaying of the variables

Load profiles

Front panel

■

How to scroll the various pages

To scroll the various pages, use the

and

keys.

Pressing the

key in any one of the display pages,

you access to the programming phase. The

key,

on the contrary, has various functions depending on the
selected page.

■

How the

key changes function depending

on the display page.

❑

Pages from "00" to "13" (00 only without measur-

ing input module). Displaying of the variables

key enabled if the alarm latch function is activated,

access to the reset of the latch alarms. To reset the latch

alarm press the

key; after that the instrument will dis-

play: “ WILL YOU RESET THE LATCH ALARMS?”; If you

choose

you will enable the reset procedure, if you

choose there

won’t be any reset. The reset of the latch

alarm is only available if the alarm event is finished.

❑

Pages from "14" to "18" (from 01 to 02 without

measuring input module). Displaying of the “MIN”
and “MAX” values.

The

key is active, that means you have access to

the reset function of the “MIN” and “MAX” values. To reset
the “MIN/MAX” recording, proceed as follows: enter the

function by pressing the

key, after that a message will

appear: “WILL YOU RESET MIN/MAX VALUES? WILL YOU

CONTINUE?"; if you choose

there won’t be any reset,

if you choose

the reset will not be made. The

and

keys allow you to select the range/value that you want

to reset; to confirm the reset press the

key again. To exit

the function press the

key again.

▼

▲

▼

▲
