Programming – Carlo Gavazzi WM4-96 User Manual

Page 19

with ;

choose

“ON” to enable the metering: the following

window appears: selection between H

O/GAS and kWh- (gen-

erated Kwh) “ENERGY METER”; choose the desired type of

counter by means of

and

, confirm with

(if you

choose the kWh- metering, also the A2 input for counting the

▼

▲

Programming

List of digital inputs

Access to the main menu

iff gas metering: to do this the
AQ1042 digital inputs + aux mod-
ule must be installed in slot A.
Choose the “INPUTS” function by

means of the

and

keys

and press

to enter in the sub-

menu. Choose the “MEASURE”

function by means of the

and

keys; press

to select the

relevant operating mode and enter
the relevant sub-menu where you
can select the digital inputs (if pres-
ent in slot A) connected to the gas,
water and energy meters.
1- Choose the A1 INPUT (gas or

kWh- meter) by means of the

and

keys (the description of

the selected input function and the
weight of the connected pulse can
be seen under the scroll window);

press to

confirm.

2- Once the ON/OFF window is
displayed, choose “OFF” by

means of the

and

keys to

disable the metering and confirm

▼

▲

▼

▲

▼

▲

▼

▲

▼

▲

▼

▲

▼

▲

▼

▲

1.2..
..2.1

▼

▲

1.2..
..2.1
