Counters Management

Multitariff counters

Graphs, AVG calcul.

▼

▲

▼

▲

1-press

: the first box (trf=tar-

iff) is highlighted;

2-press

again: the TARIFF box

will appear on the lower part of the
display; now you can choose the
tariff (from 1 to 4), e.g.: “1” by means

the and keys;

3-press the

key once more,

the “end tariff” hour is highlighted;

4-press the

key once more; the

HOURS box will appear on the
lower part of the display; now you
can choose the hours - e.g. 8 - by

means of the

and

keys.

5-press the

key again; the “end

tariff” minutes will be highlighted;

6-press the

key again: the MIN-

UTES box will appear on the lower
part of the display; now you can set
the desired minutes - e.g. 10 - by

means of the

and

keys.

7-after the confirmation of the last

setting, press

and you are back

to the selection of the first “trf”
parameter you have highlighted.
The “starting hour” of the following
line becomes equal to the “end
hour” you have just selected. Only
when the “trf” parameter is high-
lighted, you can scroll the parame-
ters and modify them: use the

key to access to the parame-

▼

▲

▼

▲

▼

▲

1.2..
..2.1

▲

1.2..
..2.1

▲

1.2..
..2.1

▼

Proceed with the
same principle for
the following rows.
To exit any item

always use
