Outputs / Other settings

SMS table

Alarms

❑

Remote control

This function enables the control
of the digital outputs by means of

▼

▲

the RS485/RS232 communication port instead of using the
instrument’s alarm. The outputs can be activated by a PC or
PLC by sending special commands. Select the REMOTE

CONTR. function by means of the

and

keys and

confirm pressing the

key: the instrument will go back to

the DIGITAL OUTPUT menu. To reset your choice and go

back to the main menu, press

▼

▲

■

Serial output

This function enables the user

to set the parameters of the serial
output. Choose “SERIAL OUT-
PUT” from the main menu by

means of the

and

keys

and confirm with

. Then, select

the type of serial output to be used.

▼

▲

▼

▲

▼

▲

▼

▲

▼

▲

❑

RS 232

Select RS232 by means of the

and

keys and confirm

with

. You enter the baud-

rate selection window. Use the

and

keys to select the

required baud rate value and

confirm with

▼

▲

▼

▲
